Online high-speed checkweigher system
Brief Introduction of Online high-speed checkweigher system
Online checkweigher is a kind of high-accuracy online
weight-checking equipment. It mainly weighs the passing packed
goods online in packing lines. It can check out
qualification/overweight/less weight of products,and eliminate or
alarm the unqualified ones; the whole inspection makes little
change in the original working process of packing line.
This kind of scale can also be applied in delivering conveyor and
be connected to computer controller so that it can greatly improve
efficiency in delivering tha packed goods and improve
accuracy,reliability,credibility of ration delivery. In this way,it
can avoid series of problem caused by human factors.
System Components
We recommend online checkweigher with computer controlling system
to meet the needs of customers.
The controlling system consists of online checkweigher,industrial
controlling computing and printer. What's more,it is equipped with
corresponding software and program to finish the managing task such
as ration delivery,data recording,and statistics,etc.
The online checkweigher mainly contains weighing indicator with
input and output,programmable controller
PLC,panel,decelerating motor,inverter,friendly man-machine
interface,and system protection,etc.
System functions:
1. Monitoring Level: Computers in the office possess three
functions as operating,monitoring and managing. Parameters of total
shipments are sent out by monitoring computer and executed by
online checkweigher.
Monitoring level carries out "vestigial management" on the
checkweigher. That is to mean that all the operation,working and
results are recorded with real time and then generate reports. The
production reports are saved in data base and can be viewed or
printed anytime you want.
2. Controlling level: Controlling level is mainly dominated by
programmable controller(PLC). PLC turns on and off corresponding
driver circuit according to control instructions to complete the
domination of equipment. It can deliver data such as working state
of equipment and collected flow to monitoring computer through
Internet with real time going.
3. Eqipment level: Checkweigher including weighing indicator,load
cell,counter,etc. is located on equipment. PLC will control the
operation of equipment,detect its operating state and collect the
operating data.
Technical parameters:
| Maxmum capacity | 60kg |
| Minimum capacity | 1.0kg |
| Displayed division value | 0.02kg |
| Dynamic weighing accuracy | ≥±20g |
| Maximum length of object | 800mm |
| Minimum distance between objects | ≥2000mm |
| Working width of belt of checkweigher | 600mm |
| Total width of checkweigher | 850mm(customizable) |
| Working length of weighing line | 1000mm(customizable) |
| Speed of belt line | 40m/min,adjustable |
